OutlineDimensions(Inch/mm)

Schematics

No. of Leads

.100 ± .005

2.54 ± 0.13

Pitch. Non-

Accumulative

.020 ± .004

0.51 ± 0.10

.012 ± .003

0.31 ± 0.08

Centered

on Package

.140 ± .020

3.56 ± 0.51

Max.

“L” Max.

Max.

12

34

n

-3 Circuit

Isolated Resistors

-5 Circuit

Dual Terminator

12

34

R1

R2

n

12

34

n

-1 Circuit

Bussed Resistors

#ofLeads

4

5

6

7

8

9

10

11

12

13

14

Dim.“L”

Max.

.40

10.16

.50

12.70

.60

15.24

.70

17.78

.80

20.32

.90

22.86

1.00

25.40

1.10

27.94

1.20

30.48

1.30

33.02

1.40

35.56

.200

.098

5.08

2.5

SIL Resistor Network

L Series

Make Possible

10.14

General Note
