DASCOUP6DBNF datasheet(2/2 Pages) PULSE

2 / 2 page

For More Information

Pulse Worldwide Headquarters

12220 World Trade Drive

San Diego, CA 92128

U.S.A.

Tel: 1 858 674 8100

Fax: 1 858 674 8262

Larsen Brand Antennas

3611 NE 112th Avenue

Vancouver, WA 98682

USA

Tel: 1 360 944 7551

Fax: 1 369 944 7556

Europe Headquarters

Pulse GmbH & Do, KG

Zeppelinstrasse 15

Herrenberg, Germany

Tel: 49 7032 7806 0

Fax: 49 7032 7806 135

Pulse (Suzhou) Wireless Products Co, Inc.

99 Huo Ju Road, (#29 Bldg, 4th Phase)

Suzhou New District

Science & Tech Industrial Park

Jiangsu Province, Suzhou 215009 PR China

Tel: 86 512 6807 9998

Fax: 86 512 6809 8023

Performance warranty of products offered on this data

sheet is limited to the parameters specified. Data is

subject to change without notice. Other brand and

product names mentioned herein may be trademarks

or registered trademarks of their respective owners.

reserved.

L178.A (07/15)

pulseelectronics.com/products/antennas

Directional Coupler,

698-2700 MHz, Low PIM

Pulse Part Number DASCOUPxxDBNF Series

Electrical Specifications

Frequency (MHz) 698-2700 MHz

Nominal Impedance Ω 50Ω

VSWR ≤1.20

Insert Loss at Band DASCOUP10DBNF

≤0.7dB @698-2700 MHz

Isolation at Band DASCOUP10DBNF

≥30dB @ 698-2700 MHz

Insert Loss at Band DASCOUP6DBNF

≤1.6dB @698-2700 MHz

Isolation at Band DASCOUP6DBNF

≥26dB @ 698-2700 MHz

Directivity ≥20 dB

PIM ≤ -155 dBc (@ 243*43dBm)

Average Power Max 200 Watts

Peak Power Max 1000 Watts

Coupling DASCOUP6DBNF

6 dB

Coupling DASCOUP10DBNF

10 dB

Coupling Tolerance ± 1.0 dB

Mechanical Specifications

Connecto

N Female

Color

Black

Inner Contact Plating

Silver

Outer Trimetal Plating

Trimetal

Environmental Specifications

Operating Temperature

-30+85 ° C

Relativy Humidity

Up to 100%
