Symbol

Description

Conditions

Min

Typical

Max

Units

Clock High Period

0.6

µs

Set-up Time for Repeated

START Condition

0.6

µs

Bus Free Time Between

STOP and START

Condition

1.3

µs

Capacitive Load for each

Bus Line

150

pF

SCL, SDA Input

Capacitance

5

pF

Thermal Shutdown

Thermal Shutdown

140

°C

Falling

120

°C

[a] Do not externally load. For internal biasing only.

[b] If the die temperature exceeds 130°C, the Thermal_SHTDN_Status flag is set and an end power transfer (EPT) packet is sent (see Table 11).
