SP2T PIN Diode Switch

Rev. V1

MSW200x-200

4

4

M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.

Visit www.macom.com for additional data sheets and product information.

For further information and support please visit:

https://www.macom.com/support

DS-xxxxxxx

4

Truth Table

RF Bias Network Component Values

Part #

Frequency (MHz)

Inductors

DC Blocking Capacitors RF Bypass Capacitors

MSW2000-200

50 - 1000

4.7 µH

0.1 µF

0.1 µF

MSW2001-200

400 - 4000

82 nH

27 pF

270 pF

MSW2002-200

2000 - 6000

33 nH

22 pF

33 pF

Evaluation Board Truth Table

Port

J0 - J1

Port

J0 - J2

Bias: B1

Bias: B2

Bias: B3

Bias: B4

Low Loss

Isolation

-100 mA

+100 mA

+25 mA @ +28 V

-25 mA

Isolation

Low Loss

+28 V

+25 mA

-25 mA

+28 V

Port

J0 - J1

Ant Bias (P1-pin 3)

TX Bias (P1-pin 1)

RX Bias (P1-pin 7)

DC Bias (P1-pin 5)

TX-ANT Low Loss &

TX-RX Isolation

+5 V @ +100 mA

0 V @ +100 mA

+28 V @ +25 mA

0 V @ +25 mA

ANT-RX Low Loss &

RX-TX Isolation

+5 V @ +100 mA

+28 V @ 0 mA

0 V @ +100 mA

+28 V @ 0 mA
