SP2T PIN Diode Switch

Rev. V1

MSW200x-200

2

2

M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.

Visit www.macom.com for additional data sheets and product information.

For further information and support please visit:

https://www.macom.com/support

DS-xxxxxxx

2

Parameter

Test Conditions

Units

Min.

Typ.

Max.

Frequency

—

MHz

50

—

1000

TX-Ant Insertion Loss

Condition 1

dB

—

0.15

0.25

Ant-RX Insertion Loss

Condition 2

dB

—

0.25

0.35

TX-Ant Return Loss

Condition 1

dB

20

22

—

Ant-RX Return Loss

Condition 2

dB

20

23

—

TX-RX Isolation

Condition 1

dB

48

52

—

RX-TX Isolation

Condition 2

dB

22

26

—

Condition 1, 1.5:1 Source & Load VSWR

dBm

—

—

50

Condition 2, 1.5:1 Source & Load VSWR

dBm

—

—

43

Condition 1, 10 µs Pulse Width, 1% Duty Cycle,

1.5:1 Source & Load VSWR (IL)

dBm

—

—

57

10% - 90% RF Voltage

µs

—

2

3

Input IP3

F1 = 500 MHz, F2 = 510 MHz, P1=P2=10 dBm

dBm

60

65

—

Continued

Parameter

Test Conditions

Units

Min.

Typ.

Max.

Frequency

—

MHz

400

—

4000

TX-Ant Insertion Loss

Condition 1

dB

—

0.3

0.4

Ant-RX Insertion Loss

Condition 2

dB

—

0.4

0.5

TX-Ant Return Loss

Condition 1

dB

15

18

—

Ant-RX Return Loss

Condition 2

dB

15

17

—

TX-RX Isolation

Condition 1

dB

32

36

—

RX-TX Isolation

Condition 2

dB

12

14

—

Condition 1, 1.5:1 Source & Load VSWR

dBm

—

—

50

Condition 2, 1.5:1 Source & Load VSWR

dBm

—

—

43

Condition 1, 10 µs Pulse Width, 1% Duty Cycle,

1.5:1 Source & Load VSWR (IL)

dBm

—

—

57

10% - 90% RF Voltage

µs

—

1.5

2.0

Input IP3

F1 = 2.0 GHz, F2 = 2.01 GHz, P1=P2=40 dBm

dBm

60

65

—
