MBR3100

Preliminary

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R202-059 .a



ABSOLUTE MAXIMUM RATING (TA=25°C, unless otherwise specified)

Ratings at 25°C ambient temperature unless otherwise specified.

Single phase half-wave 60Hz, resistive or inductive load, for capacitive load current derate by 20%.

PARAMETER

SYMBOL

RATINGS

UNIT

DC Blocking Voltage

VRM

100

Working Peak Reverse Voltage

VRWM

100

Peak Repetitive Reverse Voltage

VRRM

100

Average Rectified Output Current

3.0

Peak Forward Surge Current 8.3ms Single Half

Sine-Wave Superimposed on Rated Load

IFSM

Junction Temperature

-55 ~ +150

°C

Storage Temperature

TSTG

-55 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL CHARACTERISTICS (PER LEG)

PARAMETER

SYMBOL

RATINGS

UNIT

Typical Thermal Resistance

θJL

°C/W



ELECTRICAL CHARACTERISTICS (PER LEG) (TA =25°C unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Reverse Breakdown Voltage

V(BR)R

IR=0.50mA

100

IF=3.0A, TC=25°C

0.85

Instantaneous Forward Voltage

VFM

IF=3.0A, TC=125°C

0.70

VR=100V, TC=25°C

500

μA

Leakage Current

IRM

VR=100V, TC=125°C

2.0

Note: Pulse Test: Pulse width ≤ 300µs, Duty cycle ≤ 2%.
