SDA3611CDN Folha de dados(PDF) 2 Page - Shanghai Leiditech Electronic Technology Co., Ltd

Nome de Peças SDA3611CDN
Descrição Electrónicos  BIDIRECTIONAL TVS DIODE
PDF  3 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Fabricante Electrônico  LEIDITECH [Shanghai Leiditech Electronic Technology Co., Ltd]
Página de início  http://www.leiditech.com
Logo LEIDITECH - Shanghai Leiditech Electronic Technology Co., Ltd

SDA3611CDN Folha de dados(HTML) 2 Page - Shanghai Leiditech Electronic Technology Co., Ltd

  SDA3611CDN Datasheet HTML 1Page - Shanghai Leiditech Electronic Technology Co., Ltd SDA3611CDN Datasheet HTML 2Page - Shanghai Leiditech Electronic Technology Co., Ltd SDA3611CDN Datasheet HTML 3Page - Shanghai Leiditech Electronic Technology Co., Ltd
Zoom Inzoom in Zoom Outzoom out
 2 / 3 page
background image
Electrical Characteristics(TA=25°C unless otherwise specified)
Part Number
Device
Marking
VRWM
(V)
VBR
(V)
IT
(mA)
VC
@1A
Vc
IR
μA
(Max)
C
(Pf)
(Typ.)
(Max)
(@A)
SDA3611CDN
DN
36
40
1
42
75
2
1
20
Characteristic Curves
Fig1.
8/20µ s Pulse Waveform
0
5
10
15
20
25
30
120
tr
100
80
60
40
20
0
Peak Value IPP
td=t IPP/2
TEST
WAVEFORM
PARAMETERS
tr=8 s
td=20 s
t - Time ( s)
Fig3.
Power Derating Curve
0
25
50
75
100
125
150
110
100
40
30
20
10
0
90
80
70
60
50
Ambient Temperature –TA (ºC)
Fig2. ESD Pulse Waveform (according to IEC 61000-4-2)
60ns
10%
30ns
tr = 0.7~1ns
Time (ns)
90%
100%
Rev : 01.06.2014
2/3
www.leiditech.com
SDA3611CDN
