PL602-XX
HCSL Compatible Clock Generator for PCI Express
Micrel Inc. • 2180 Fortune Drive • San Jose, CA 95131 • USA • tel +1(408) 944 -0800 • fax +1(408) 474-1000 • www.micrel.com Rev 02/08/11 Page 3
DC SPECIFICATIONS
PARAMETERS
SYMBOL
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Supply Current, Dynamic
IDD
At 100MHz, No Load
25
mA
Operating Voltage
VDD
2.25
3.63
V
Output Low Voltage
VOL
HCSL termination,
(RS = 150Ω, RT = 49.9Ω) 3.3V
(RS = 100Ω, RT = 49.9Ω) 2.5V
0.05
V
Output High Voltage
VOH
0.65
0.75
0.85
V
Output Current
IOSD
13
15
17
mA
CRYSTAL SPECIFICATIONS
PARAMETERS
SYMBOL
MIN.
TYP.
MAX.
UNITS
Fundamental Crystal Resonator Frequency
FXIN
25
MHz
Crystal Loading Rating
CL (xtal)
18
pF
Maximum Sustainable Drive Level
500
W
Operating Drive Level
100
W
Crystal Shunt Capacitance
C0
6
pF
Effective Series Resistance, Fundamental
ESR
45
Ω



Html Pages

1 2 3 4 5 6


Folha de dados Download

Go To PDF Page


Ligação URL
