AT86RF211

1942C–WIRE–06/02

Reset Register (RESET)

Writing in this register (0 or 1) triggers an asynchronous reset. This register can only be

written.

All registers return to reset state. The chip returns in power-down. So all the following

blocks are reset:

•

All registers to default value

•

Wake-up function.

•

Clock recovery function.

And with the power-down state, reset is applied to the following blocks:

•

Synthesizer dividers.

•

Clock recovery function.

•

PLL lock detect.

•

From powering up the supplies, it takes about 10 µs or at least 1.8V before the reset

state is established (Power-on Reset).

•

From reseting the device, one should wait about 10 µs before re-programming

•

RSSI detection block.

•

Discriminator clock (455 kHz).

Control Register (CTRL1)

Name

RESET

nbit

Table 5. CTRL1 Overview

Name

PDN

RXTX

DATACLK

TXLOCK

PAPDN

WUEN

LNAGSEL

MVCC

TRSSI

HRSSI

nbit

23-18

17-15

init

(000000)

(000)

Name

TXLVL

TXFS

RXFS

XTALFQ

FSKBW

FSKPOL

DSREF

MOFFSET

nbit

14-12

9-8

init

(000)2

(10)2
