7 / 18 page

INTEGRATED CIRCUITS DIVISION

CPC5622

R03

www.ixysic.com

2.1.1 Resistive Termination Application Circuit Part List

Quantity

Reference Designator

Description

Supplier(s)

1C1

F, 16 V, ±10%

AVX, Murata, Novacap, Panasonic,

SMEC, Tecate, etc.

C2, C4, C9, C13, C14

0.1

F, 16 V, ±10%

C7, C8 1

220 pF, ±5%

C10, C15

0.01

F, 500 V, ±10%

C12

0.027

F, 16 V, ±10%

1C16

F, 16 V, ±10%

C18 (optional)

15 pF, 16 V, ±10%

C21

100 pF, 16 V, 10%

80.6 k

, 1/16 W, ±1%

Panasonic, Electro Films, FMI, Vishay,

etc.

130 k

, 1/16 W, ±1%

1.5 M

, 1/16 W, ±1%

68.1

, 1/16 W, ±1%

60.4 k

, 1/16 W, ±1%

R6, R7, R44, R45 2

1.8 M

, 1/10 W, ±1%

221 k

, 1/16 W, ±1%

R10

301

, 1/16 W, ±1%

R12

499 k

, 1/16 W, ±1%

1R13

1 M

, 1/16 W, ±1%

1R14

, 1/16 W, ±5%

R15

1.69 M

, 1/16 W, ±1%

R16

8.2

, 1/8 W, ±1%

R18

3.32 k

 1/16 W, ±1%

1R20

, 1/16 W, ±5%

R21, R22

6.49 M

, 1/16 W, ±1%

1R23

 1/16 W, ±5%, or 220 H inductor

R75

261 k

, 1/16 W, ±1%

R76

200 k

, 1/16 W, ±1%

FB1

600

, 200 mA ferrite bead

Murata BLM11A601S or similar

DB1

S1ZB60 bridge rectifier

Shindengen, Diodes, Inc.

SP1

350 V

Bourns (TISP4350H3) or

Teccor (P3100SC)

CPC5602 FET

IXYS Integrated Circuits Division

CPC5622 LITELINK

1Use voltage ratings based on the isolation requirements of your application. Typical applications will require 2kV to safely hold off the isolation voltage.

2Use components that allow enough space to account for the possibility of high-voltage arcing.
