ACDSW4148-G

Page 1

AQW-B0001

SMD Switching Diode

RoHS Device

REV:A

°C

°C

°C/W

mW

mA

V

250

350

150

71

-55~+150

Io

Storage temperature range

Junction temperature range

Power dissipation

Non-Repetitive peak forward surge current @t=1µs

Average rectified output current

V

100

Peak repetitive peak reverse voltage

Working peak reverse voltage

DC blocking voltage

Parameter

Symbol

Value

Unit

RMS reverse voltage

Thermal resistance from junction to ambient

2

A

Comchip Technology CO., LTD.

-40~+150

Company reserves the right to improve product design , functions and reliability without notice.

0.152(3.85)

0.140(3.55)

0.045(1.15)

0.041(1.05)

Dimensions in inches and (millimeter)

SOD-123

0.020(0.50) REF

0.004(0.10) Max.

0.110(2.80)

0.102(2.60)

0.067(1.70)

0.059(1.50)

0.026(0.65)

0.018(0.45)

0.006(0.15)

0.003(0.08)

Circuit diagram

Mechanical data

- Case: SOD-123, Molded Plastic

- Weight: 0.0097 grams(approx.).

method 2026.

Reverse Voltage: 100 V

Features

- Fast switching speed

- High conductance

- Surface mount package ideally suited for

automatic insertion

- For general purpose switching applications

- Comply with AEC-Q101

- High speed

Forward Current: 150mA

-

+
