Data Sheet

ADA8282

Rev. 0 | Page 5 of 21

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Electrical

AVDD to EPAD

−0.3 V to +3.9 V

+INx, −INx, SCLK, SDI, SDO, CS, VIO, RESET,

−OUTx, +OUTx to EPAD

−0.3V to AVDD +

0.3 V

ESD Ratings

Human Body Model (HBM)

±4000 V

Charged Device Model (CDM)

±2000 V

Environmental

Operating Temperature Range (Ambient)

−40°C to +125°C

Storage Temperature Range (Ambient)

−65°C to +150°C

Maximum Junction Temperature

150°C

Lead Temperature (Soldering, 10 sec)

300°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 4. Thermal Resistance

Package Type

θJA

θJC

Unit

32-Lead, 5 mm × 5 mm LFCSP

33.51

4.1

°C/W

ESD CAUTION
