JH177128160B
VER: 1.0
- 9 -
Issue date: 2013/08/12
JEWEL HILL ELECTRONIC CO.,LTD.
PIN
NO. PIN OUT
FUNCTION DESCRIPTION
1
VSS
Ground
2
LED-K
LED Negative
3
LED-A
LED Positive
4
VSS
Ground
5
/REST
System Reset Pin
6
AO
Data/Command Write Select pin
7
SDA
Serial data input pin
8
SCL
Serial I/F Synchronous clock signal
9
VDDA
Power Supply
10
VDDIO
Power Supply(1.8-2.8)
11
/CS
Chip select input pin
12
VSS
Ground
13
YD
NC
14
XL
NC
15
YU
NC
16
XR
NC
17
VSS
Ground
18
VSS
Ground
8.Outline Dimension
