EX95000 Series

www.EtherWAN.com

rev. A2

Environment

OperatingTemperature

•-40°C to 75°C (-40°F to 167°F)

StorageTemperature

•-40°C to 85°C (-40°F to 185°F)

AmbientRelativeHumidity

•5% to 95% (non-condensing)

RegulatoryApprovals

ISO

•Manufactured in an ISO9001 facility

Safety

UL508

EMI

FCCPart15B,ClassA

VCCIClassA

EN61000-6-4

EN55022

EN61000-3-2

EN61000-3-3

EMS

EN61000-6-2

•EN61000-4-2 (ESD Standards)

•EN61000-4-3 (Radiated RFI Standards)

•EN61000-4-4 (Burst Standards)

•EN61000-4-5 (Surge Standards)

•EN61000-4-6 (Induced RFI Standards)

•EN61000-4-8 (Magnetic Field Standards)

EnvironmentalTestCompliance

IEC60068-2-6Fc(Vibration)

IEC60068-2-27Ea(Shock)

FEDSTD101CMethod5007.1(Freefallw/package)

IndustrialCompliance

NEMATS2

Hardware Specifications

Technology

Standards

•IEEE802.3 10BASE-T

•IEEE802.3u 100BASE-TX/100BASE-FX

•IEEE802.3x Full duplex and flow control

ForwardandFilteringRate

•14,880pps for 10Mbps

•148,810pps for 100Mbps

PacketBufferMemory

•1.625M bits

ProcessingType

•Store-and-Forward

•Auto Negotiation

•Half-duplex back-pressure and IEEE802.3x full-duplex flow

control

•Auto MDI/MDIX

AddressTableSize

•4096 MAC addresses

Latency

•Lessthan10μs

Power

InputVoltage

•12 to 48VDC (Terminal Block)

•12VDC (DC Jack)

PowerConsumption

•7.4W Max. 0.6A @ 12VDC

•0.3A @ 24VDC

•0.15A @ 48VDC

Protection

•Overload current protection

Mechanical

Casing

•Aluminum Case

•IP30

Dimensions

•75.5mm (W) x 110mm (D) x 135mm (H)

(2.98" (W) x 4.33" (D) x 5.31" (H))

Weight

•0.87Kg (1.92lbs.)

Installation

•DIN-Rail (Top hat type 35mm), Panel, Rack mounting

Interface

EthernetPorts

•10/100BASE-TX: 16, 15 or 14 ports

•100BASE-FX: 0, 1 or 2 ports

LEDIndicators

•Per Unit: Power 1 (Green),

Power 2 (Green),

Power 3 (Green)

•Per Port: Link/Activity (Green)

AlarmContact

•One relay output with current 1A @ 24VDC
