Table 6.5 shows which reset sources generate certain resets.
6.3. Clocks
The EM341 integrates four oscillators:

12 MHz RC oscillator

24 MHz crystal oscillator

10 kHz RC oscillator

32.768 kHz crystal oscillator
Figure 6.2 shows a block diagram of the clocks in the EM341. This simplified view shows all the clock sources and
the general areas of the chip to which they are routed.
Figure 6.2. Clocks Block Diagram
Table 6.5. Generated Resets
Reset Source
Reset Generation Module Output
PORESET SYSRESET DAPRESET PRESETHV PRESETLV
POR HV
X
X
X
X
X
POR LV (due to waking from
normal deep sleep)
X
X
X
X
POR LV (not due to waking from
normal deep sleep)
X
X
X
X
X
nRESET
X
X
X
X
Watchdog
X
X
X
SYSRESETREQ
X
X
X
Option byte error
X
X
X
Normal deep sleep
X
X
X
X
Emulated deep sleep
X
X
Debug reset
X
