MBR160

Preliminary

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R601-260.c



ABSOLUTE MAXIMUM RATING (TA=25°C, unless otherwise specified)

Ratings at 25°C ambient temperature unless otherwise specified.

Single phase half-wave 60Hz, resistive or inductive load, for capacitive load current derate by 20%.

PARAMETER

SYMBOL

RATINGS

UNIT

Working Peak Reverse Voltage

VRWM

Repetitive Peak Reverse Voltage

VRRM

Maximum RMS Reverse Voltage

VRMS

DC Blocking Voltage

Average Rectified Output Current (TA=105°C)

1.0

Peak Forward Surge Current 8.3ms Single Half

Sine-Wave Superimposed on Rated Load

IFSM

Junction Temperature

-55~+150

°C

Storage Temperature

TSTG

-55~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

θJA

°C/W



ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Instantaneous Forward Voltage Drop (Note 2)

IF=1.0A, TC=25°C

0.74

IF=1.0A, TC=125°C

0.69

Instantaneous Reverse Current (Note 2)

Rated DC Voltage, TC=25°C

μA

Rated DC Voltage, TC=125°C

Notes: 1. 2.0μs Pulse Width, f = 1.0KHz.

2. Pulse Test: Pulse Width ≤ 300µs, Duty Cycle ≤ 2.0%.
