PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage Range

-0.3 ~ +6.0

V

Positive Output Supply Voltage Range (Note 2)

V+

-0.3 ~ +7.0

V

Negative Output Supply Voltage Range (Note 2)

V-

+0.3 ~ -7.0

V

Supply Voltage Difference (Note 2)

V+ - V-

+13

V

Input Voltage

Drivers

-0.3 ~ +6.0

V

Receivers

-25 ~ +25

V

Output Voltage

Drivers

-13.2 ~ +13.2

V

Receivers

V

Operating Virtual Junction Temperature

+150

°C

Storage Temperature

-65 ~ + 150

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. All voltages are with respect to network GND.



THERMAL DATA

PARAMETER

SYMBOL

RATING

UNIT

Junction to Ambient

SOP-16

105

°C/W

TSSOP-16

118



PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Supply Voltage

3.0

3.3

3.6

V

4.5

5.0

5.5

V

Driver and Control High-level Input

Voltage

DIN

2.0

V

2.4

Driver and Control Low-level Input

Voltage

DIN

0.8

V

Driver and Control Input Voltage

DIN

5.5

V

Receiver Input Voltage

-25

25

V

Operating Free-Air Temperature

0

70

°C
