CONSMA007-R178 Folha de dados(PDF) 1 Page - List of Unclassifed Manufacturers

Nome de Peças CONSMA007-R178
Descrição Electrónicos  SMA MALE CABLE END CRIMP FOR RG178 CABLE
PDF  1 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Fabricante Electrônico  ETC2 [List of Unclassifed Manufacturers]
Página de início
Logo ETC2 - List of Unclassifed Manufacturers

CONSMA007-R178 Folha de dados(HTML) 1 Page - List of Unclassifed Manufacturers

  CONSMA007-R178 Datasheet HTML 1Page - List of Unclassifed Manufacturers
Zoom Inzoom in Zoom Outzoom out
 1 / 1 page
background image
A
B
C
D
4
3
2
1
D
C
B
A
1
2
4
3
SMA MALE CABLE END
CRIMP FOR RG178 CABLE
0.254
(6.50)
0.177
(4.50)
RECOMMENDED CABLE STRIPPING DIMENSIONS
0.118
(3.00)
RG-178 Cable
1. Strip the cable to the recommended dimensions.
2. Solder the support onto the braid.
3. Place the spacer onto the center conductor.
4. Solder or crimp the pin onto the center conductor.
5. Insert the pin, center conductor, spacer, and support into the body
until the top of the pin is even with the body.
6. Crimp the tail of the body onto the support with a hex crimp tool.
CONSMA007-R178 ASSEMBLY INSTRUCTIONS
Description
Material
Finish
Body
Pin
Insulation
Nickel
Teflon
Gold
Teflon
Brass
BE CU
Washer
PH Bronze
Gold
Gasket
Rubber
SI Rubber
Crimp Ring
Nickel
Brass
CONNECTOR CITY
159 ORT LANE
MERLIN, OR 97532
PH (541)-471-6256
FAX (541)-471-6251
Date:
Sheet 1 of 1
Revision:
Title
Part No.
Dimensions:
CONSMA007-R178
1.0
INCHES (mm)
6/2/2006
0.197
(5.00)
0.577
(14.65)
Ø0.102
(2.60)
1/4-36UNF-2B
THREADS
H0.311
(7.90)
Spacer
Teflon
Teflon
Support
Gold
Brass
SPACER
SUPPORT
0.335
(8.50)
Ø0.049
(1.25)
0.102
(2.60)
Ø0.035
(0.90)
Ø0.024
(0.60)
SIDE VIEW
PIN
