NJG1553BF
- 8 -
nMEASURING BLOCK DIAGRAM
IF, IM3 Measuring Block Diagram
Noise Figure Measuring Block Diagram
SG
(RF1)
SG
(RF2)
SG
(LO)
Power
Comb.
6dB ATT
ISO.1
ISO.2
DUT
Spectrum
Analyzer
RFIN
LOIN
IFOUT
VMIX=VLO=2.7V
SG
(LO)
BPF
BPF 6dB ATT
DUT
RFIN
LOIN
IFOUT
NF
Meter
Noise
Source
VMIX=VLO=2.7V
