RF Power Amplifier IC for 2.4 GHz ISM

MA02303GJ

Specifications subject to change without notice.

n North America: Tel. (800) 366-2266

n Asia/Pacific: Tel.+81-44-844-8296, Fax +81-44-844-8298

n Europe: Tel. +44 (1344) 869 595, Fax+44 (1344) 300 020

Visit www.macom.com for additional data sheets and product information.

Electrical Specifications: VDD = +3.3 V, PIN = -2 dBm, Duty Cycle = 100 %,

TS = 37 °C (Note 1), measured on evaluation board shown in Figure 11.

Characteristic

Symbol

Min.

Typ.

Max.

Unit

Frequency Range

2400

2500

MHz

Output Power, ƒ = 2450 MHz

POUT

25.3

26.5

—

dBm

Power Added Efficiency, ƒ = 2450 MHz

Current, ƒ = 2450 MHz

IDD

265

415

Current for linear operation, ƒ = 2450 MHz,

PIN adjusted for POUT = 20.0 dBm +/- 0.2 dBm

IDD

415

Gain, ƒ = 2450 MHz,

PIN adjusted for POUT = 20.0 dBm +/- 0.2 dBm

29.5

Harmonics, ƒ = 2450 MHz

2ƒ, 3ƒ, 4 ƒ

-40

dBc

Input VSWR, ƒ = 2450 MHz

—

2.0:1

—

Off Isolation (VDD=0 V)

—

Thermal Resistance, junction to package bottom

RTH

°C/W

Third Order Intercept Point

IP3

dBm

Load Mismatch (VDD = 5.5 V, VSWR = 8:1, PIN = 0 dBm)

—

No Degradation in Power Output

Stability (PIN = -2 to 2 dBm, VDD = 0-5.5 V, Load VSWR = 5:1,

all phases)

—

All non-harmonically related outputs more

than 60 dB below desired signal

1. TS is the temperature measured at the soldering point of the downset paddle on the bottom of the IC.
