3 / 4 page  www.roithner-laser.com 3 Outline Dimensions All Dimensions in mm Operating Regime We recommend to use Quasi Continuous Wave (qCW) mode with duty cycle 50% or 25% to obtain maximum average optical power, and short Pulse mode to obtain maximum peak power. CW (continuous wave) mode is NOT recommended! LED23 TO-18, without window Material – kovar, finish – gold/plating Lead Description PIN 1 LD Anode PIN 2 LD Cathode LED Basic Circuit Connection Suitable Drivers And Evaluation Boards • D-31M • D-41 • D-51 • mD-1c • mD-1p Quasi Continuous Wave (qCW) mode Pulse Mode |
|
|
