µPC2800A

6

4. ELECTRICAL SPECIFICATIONS

Parameter

Symbol

Rating

Unit

Supply voltage

6.0

V

Output current

2.5

mA

Input voltage

V

Permissible package loss

270

mW

Operating temperature

–20 to +75

°C

Storage temperature

–40 to +125

°C

Caution If any of the parameters exceeds the absolute maximum ratings, even momentarily, the

quality of the product may be impaired. The absolute maximum ratings are values that may

physically damage the product(s). Be sure to use the product(s) within the ratings.

Recommended Operating Range

Parameter

Symbol

MIN.

TYP.

MAX.

Unit

Supply voltage

4.5

5.0

5.5

V

Input frequency

30

38

80

kHz

Parameter

Symbol

Condition

MIN.

TYP.

MAX.

Unit

Supply current

2.1

2.8

mA

Input pin voltage

2.0

2.5

3.1

V

Input pin voltage

µA

0.6

0.8

1.7

V

Voltage gain

74

78

82

dB

BPF bandwidth

2.0

2.5

3.0

kHz

Internal input resistance

60

90

140

k

Ω

Output pulse width 1

440

770

µs

Output pulse width 2

440

770

µs

Low-level output voltage

0.2

0.4

V

High-level output voltage

4.8

5.0

V

Note

600 s 600 s

38-kHz carrier

Input burst wave

Output pulse width

µ

µ
