Space-saving ultra-compact housing

Keyhole mounting flanges enable secure wallmount installation

Optional PDUB15 bypass PDU enables hot-swappable UPS replacement with no disruption to connected equipment

$100,000 Ultimate Lifetime Insurance protects connected equipment from surge damage (U.S., Canada, and Puerto Rico only)

Specifications

OUTPUT

Output Volt Amp Capacity (VA)

900

Output Watt Capacity (Watts)

480

Nominal Output Voltage(s)

Supported

115V; 120V

Frequency Compatibility

60 Hz

Output Voltage Regulation (Battery

Mode)

115V (+/- 5%)

UPS Output Receptacles

12 5-15R outlet(s)

UPS Output Receptacles (Surge

Suppression Only)

6 UPS outlets, 6 surge-only outlets

Hot-Swap PDU options

PDUB15 (2U / 8 5-15R outlets)

Output AC Waveform (AC Mode)

Sine wave

Output AC Waveform (Battery Mode)

PWM sine wave

INPUT

Rated input current (Maximum Load)

10A

Nominal Input Voltage(s) Supported

120V AC

UPS Input Connection Type

5-15P

Input Circuit Breakers

10A

UPS Input Cord Length (ft.)

6

UPS Input Cord Length (m)

1.8

Recommended Electrical Service

15A 120V

Input Phase

Single-Phase

BATTERY

Half Load Runtime (min.)

10 min. (240w)

DC System Voltage (VDC)

12

LEDS ALARMS & SWITCHES

LED Indicators

2 LEDs indicate power status and overload/check battery status

2 / 4
