Current in Amps

13

5

8

12

10

15

18

20

25

30

Time-Current Curve

Packaging Code

Packaging Code

Description

BK

100 fuses packed into a cardboard carton

BK1

1,000 fuses packed into a cardboard carton

BK8

8,000 fuses packed into a cardboard carton

Option Code

Option Code

Description

V

Axial leads - copper tinned wire with nickel plated brass overcaps

The only controlled copy of this Data Sheet is the electronic read-only version located on the Cooper Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This bulletin is

intended to clearly present comprehensive product data and provide technical information that will help the end user with design applications. Cooper Bussmann reserves the right, without notice, to change

design or construction of any products and to discontinue or limit distribution of any products. Cooper Bussmann also reserves the right to change or update, without notice, any technical information contained

in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.

Life Support Policy: Cooper Bussmann does not authorize the use of any of its products for use in life support devices or systems without the express written approval of an officer of the Company. Life support

systems are devices which support or sustain life, and whose failure to perform, when properly used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in

significant injury to the user.

0909

BU-SB09836

Page 2 of 2
