CCVGA7C5

Preliminary

TVS

UNISONICTECHNOLOGIESCO.,LTD

4 of 6

www.unisonic.com.tw

QW-R223-021.a



ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage Inputs

GND-0.5 ~ +6.0

V

Diode Forward Current

(One Diode Conducting at a Time)

20

mA

DC Voltage at Inputs

R, G, B

V

HSYNC, VSYNC

V

DDC_CLK, DDC_DATA

V

Package Power Rating

750

mW

Operating Temperature Range

0 ~ +70

°C

Storage Temperature Range

−40 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



STANDARD OPERATING CONDITIONS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Main Supply Voltage

4.5

5.5

V

RGB Supply Voltage

1.7

3.7

V

Auxiliary Supply Voltage

2.9

3.7

V

Logic High Input Voltage (Note)

2.0

V

Logic Low Input Voltage (Note)

0.8

V

Input Voltage

RGB

0

V

HSYNC, VSYNC

0

V

DDC_CLK, DDC_DATA

0

V

High Level Output Current (Note 1)

-8

mA

Low Level Output Current (Note 1)

8

mA

Free−Air Operating Temperature

0

+70

°C

Note: These parameters apply only to the HSYNC and VSYNC signals.
