1 / 31 page  This is information on a product in full production. March 2013 DocID024293 Rev 1 1/31 31 TSX631, TSX632, TSX634, TSX631A, TSX632A, TSX634A Micropower (45 μA, 200 kHz) rail-to-rail 16 V CMOS operational amplifiers Datasheet - production data Features • Low power consumption: 60 µA max at 16 V • Supply voltage: 3.3 V to 16 V • Rail-to-rail input and output • Gain bandwidth product: 200 kHz typ • Low offset voltage: – 500 µV max for “A” version – 1 mV max for standard version • Low input bias current: 1 pA typ • Automotive qualification Benefits • Power savings in power-conscious applications • Easy interfacing with high impedance sensors Related products • See TSX56x or TSX92x series for higher gain bandwidth products (900 kHz or 10 MHz) Applications • Industrial signal conditioning • Automotive signal conditioning • Active filtering • Medical instrumentation • High impedance sensors Description The TSX63x and TSX63xA series of operational amplifiers offer low voltage operation and rail-to- rail input and output. TSX631 is the single version, TSX632 the dual version and TSX634 the quad version, with pinouts compatible with industry standards. The TSX63x and TSX63xA series offer a 200 kHz gain bandwidth product while consuming 60 µA maximum at 16 V. The devices are housed in the tiniest industrial packages. These features make the TSX63x and TSX63xA family ideal for sensor interfaces and industrial signal conditioning. The wide temperature range and high ESD tolerance ease the use in harsh automotive applications. SOT23-5 DFN8 2x2 MiniSO-8 QFN16 3x3 TSSOP14 Single Dual Quad Table 1. Device summary Op-amp version Standard Vio Enhanced Vio Single TSX631 TSX631A Dual TSX632 TSX632A Quad TSX634 TSX634A www.st.com |
