NIPPON CHEMI-CON CORPORATION

1556

Engineering Bulletin

Miniature Aluminum Electrolytic Capacitors

Low impedance, 105

℃

No.804G / Mar.2012

Tentative

1

Specifications in this bulletin are subject to change without notice.

●

Adoption of innovative electrolyte and new technologies

●

Very low impedance at high frequency

●

Endurance with ripple current: 4,000 to 7,000 hours at 105

℃

●

Solvent resistant type

●

RoHS Compliant

◆SPECIFICATIONS

(at 20

℃, 120Hz)

(at 20

℃ after 2 minutes)

(at 20

℃, 120Hz)

Category

Temperature Range

Rated Voltage Range

Capacitance Tolerance

Leakage Current

Dissipation Factor

(tan

δ)

Endurance

Shelf Life

Items

±20% (M)

I=0.01CV or 3

µA, whichever is greater.

Where, I : Max. leakage current (

µA), C : Nominal capacitance (µF), V : Rated voltage (V)

tan

δ(Max.)

When nominal capacitance exceeds 1,000

µF, add 0.02 to the value above for each 1,000µF increase.

The following specifications shall be satisfied when the capacitors are restored to 20

℃ after subjected to DC voltage with the rated

ripple current is applied (the peak voltage shall not exceed the rated voltage) for the specified period of time at 105

℃.

Rated voltage

Time

φ

Capacitance change

≦±30% of the initial value

D.F.(tan

δ)

≦300% of the initial specified value

Leakage current

≦The initial specified value

The following specifications shall be satisfied when the capacitors are restored to 20

℃ after exposing them for 1,000 hours at 105℃ without

voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.

Rated voltage

Capacitance change

≦±30% of the initial value

D.F.(tan

δ)

≦300% of the initial specified value

Leakage current

≦The initial specified value

≦±20% of the initial value

≦200% of the initial specified value

≦The initial specified value

≦±20% of the initial value

≦200% of the initial specified value

≦The initial specified value

≦±20% of the initial value

≦200% of the initial specified value

≦The initial specified value

≦±20% of the initial value

≦200% of the initial specified value

≦The initial specified value

Characteristics

6.3V

0.22

10V

0.19

16V

0.16

25V

0.14

35V

0.12

◆

◆

DIMENSIONS [mm]

PART NUMBERING SYSTEM

F

L'

12.5

0.6

5.0

10

0.6

5.0

φD+0.5max.

L+1.5max.

18

0.8

7.5

16

0.8

7.5

L'

15min.

4min.

Vent

Sleeve (PET : Dark blue)

(

φ10)

(

φ12.5 to φ18)

Gas escape end seal

●

Terminal Code : E

Supplement code

Size code

Capacitance tolerance code

Capacitance code (ex. 680

µF:681, 2,200µF:222)

Lead forming·taping code

Terminal code

Voltage code (ex. 6.3V:6R3, 25V:250)

Series code

Category

M

13

4

2

6

789

10

3

1

2

1

5

8

1

7

1

6

1

1

115

14

-

55 to +105

℃

Low Temperature

Characteristics

(Max. Impedance Ratio)

Z(-55

℃)/Z(+20℃)

6.3V

4

10V

3

16V

3

25V

3

35V

3

(at 120Hz)
