Data Sheet
ADA4077-2
Rev. 0 | Page 13 of 20
Figure 42. Small Signal Transient Response
Figure 43. Positive Overload Recovery
Figure 44. Negative Overload Recovery
Figure 45. Small Signal Transient Response
Figure 46. Positive Overload Recovery
Figure 47. Negative Overload Recovery
TIME (100µs/DIV)
VSY = ±5V
VIN = 200mV p-p
AV = 1
RL = 2kΩ
CL = 1000pF
0V
TIME (10µs/DIV)
0.5
0
–0.5
–1
1
3
5
VSY = ±5V
AV = –100
VIN = 200mV
RL = 10kΩ
INPUT
OUTPUT
TIME (10µs/DIV)
0.5
0
–0.5
–5
–3
–1
1
VSY = ±5V
AV = –100
VIN = 200mV
RL = 10kΩ
INPUT
OUTPUT
TIME (100µs/DIV)
VSY = ±15V
VIN = 200mV p-p
AV = 1
RL = 2kΩ
CL = 1000pF
0V
TIME (10µs/DIV)
0.5
0
–0.5
–2
0
2
4
6
8
10
12
14
16
VSY = ±15V
AV = –100
VIN = 200mV
RL = 10kΩ
INPUT
OUTPUT
TIME (10µs/DIV)
0.5
0
–0.5
–15
–10
–5
0
VSY = ±15V
AV = –100
VIN = 200mV
RL = 10kΩ
INPUT
OUTPUT
