M24512-R_12 datasheet(24/40 Pages) STMICROELECTRONICS

24 / 40 page

DC and AC parameters

M24512-W M24512-R M24512-DR M24512-DF

24/40

Doc ID 16459 Rev 26

DC and AC parameters

This section summarizes the operating and measurement conditions, and the DC and AC

characteristics of the device.

Table 6.

Operating conditions (voltage range W)

Symbol

Parameter

Min.

Max.

Unit

VCC

Supply voltage

2.5

5.5

Ambient operating temperature

–40

°C

Operating clock frequency

1(1)

For devices identified by process letter K.

MHz

Table 7.

Operating conditions (voltage range R)

Symbol

Parameter

Min.

Max.

Unit

VCC

Supply voltage

1.8

5.5

Ambient operating temperature

–40

°C

Operating clock frequency

1(1)

For devices identified by process letter K.

MHz

Table 8.

Operating conditions (voltage range F)

Symbol

Parameter

Min.

Max.

Unit

VCC

Supply voltage

1.7

5.5

Ambient operating temperature

–40

°C

Operating clock frequency

1(1)

For devices identified by process letter K.

MHz

Table 9.

AC measurement conditions

Symbol

Parameter

Min.

Max.

Unit

Cbus

Load capacitance

100

SCL input rise/fall time, SDA input fall time

Input levels

0.2 VCC to 0.8 VCC

Input and output timing reference levels

0.3 VCC to 0.7 VCC
