M24LR64E-R
Application family identifier (AFI)
Doc ID 022712 Rev 3
61/140
14
Application family identifier (AFI)
The AFI (application family identifier) represents the type of application targeted by the VCD
and is used to identify, among all the M24LR64E-Rs present, only those that meet the
required application criteria.
Figure 47.
M24LR64E-R decision tree for AFI
The AFI is programmed by the M24LR64E-R issuer (or purchaser) in the AFI register. Once
programmed and locked, it can no longer be modified.
The most significant nibble of the AFI is used to code one specific or all application families.
The least significant nibble of the AFI is used to code one specific or all application
subfamilies. Subfamily codes different from 0 are proprietary.
(See ISO 15693-3 documentation.)
AI15130
Inventory request
received
No
No answer
Yes
No
AFI value
= 0?
Yes
No
AFI flag
set?
Yes
Answer given by the M24RF64
to the Inventory request
AFI value
= Internal
value?
