DC Line Filters VOL.10

●All specifications in this catalog and production status of products are subject to change without notice. Prior to the purchase, please contact NEC TOKIN for updated product data.

●Please request for a specification sheet for detailed product data prior to the purchase.

●Before using the product in this catalog, please read "Precautions" and other safety precautions listed in the printed version catalog.

9634DCLVOL10E1106E2

DIP Type

Common Mode Signal Line

5.08

5.08

N2

N1

1

2

3

4

7.5 max.

1

2

4

3

5.08±0.5

(1.0)

2.54 ±0.3

(ø0.6)

7.5max.

1

2

3

4

Shape and Dimensions

Circuit Diagram

SBT-01W Series

[RoHS Compliant]

SBT-0115W

50

500

30

–25 to +70

SBT-0140W

50

500

40±35%

40

–25 to +70

Bulk (100pcs.)

SBT-0160W

50

500

60±35%

45

–25 to +70

SBT-0180W

50

500

80±35%

55

–25 to +70

Rated voltage

Rated current

Inductance

DC resistance

Operating

Model

(1kHz, 70mA)

temperature range

Packaging

DC (V)

(mA)

(µH)

(m ) max.

(˚C)

SBT-01W Series

[RoHS Compliant]

10000

1000

100

10

1

0115W

0140W

0160W

0180W

Frequency (MHz)

1

10

100

1000

Impedance vs. Frequency

• Withstanding voltage: 200VDC (one minute, between lines)

• Insulation resistance: more than 10M

(100VDC, between lines)

[mm]

[mm]
