A-USB-2-R Folha de dados(PDF) 1 Page - Assmann Electronics Inc. |
|
|
|||||||||||||||||||||||||||||
A-USB-2-R Folha de dados(HTML) 1 Page - Assmann Electronics Inc. |
|
|
1 / 1 page  1 P 1 P 4 3 2 1 4 3 1 2 P1 1 2 3 4 P2 1 2 3 4 29±1MM 12±1MM Drain Unit: MM Material: • Cable: UL1007 28AWG L=30MM • P1 Connector: USB B male - Pin Gold Flash short body - Shell Plate Nickel • P2 Connector: USB A female - Pin Gold Flash short body - Shell Plate Nickel • Jacket: Beige 40P PVC Electrical: • 100% Test (Open, Short, Miss wire) • Hi-Pot: 300V DC/10ms 1 2 3 4 5 6 7 1 2 3 4 5 6 7 A B C D E F G H A B C D E F G H Item No. Drawing No. Title Name Chappell Drawn 10.19.11 Approved Modification Date Name Scale TOLERANCE 1:1 X.X X.XX X.XXX Angle ±0.40 ±0.25 ±0.15 ±3° Replace Sheet A-USB-2-R USB Adapter - A type Female <=> B type Male Version 1.1 & 2.0 Complaint RoHS rev00 |
