SSM2804
Rev. 0 | Page 16 of 36
SOFT TRANSITION (32µs TO 256µs)
NORMAL TRANSITION
0.5dB
0.5dB
ALC Soft Transition
The ALC operation of the SSM2804 incorporates techniques to
reduce the audible artifacts associated with gain change transi-
tions. First, the gain is changed in small increments of 0.5 dB.
In addition to this small step size, the rate of gain change is
reduced, proportional to the attack time setting. This feature
drastically reduces and virtually eliminates the presence of zipper
noise and other artifacts associated with gain transitions during
ALC operation. Figure 34 shows the soft transition operation.
Figure 34. Soft Transition
