AD8436

Rev. 0 | Page 4 of 20

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage

±18 V

Internal Power Dissipation

18 mW

Input Voltage

±VS

Output Short-Circuit Duration

Indefinite

Differential Input Voltage

+VS and −VS

Temperature

Operating Range

−40°C to +125°C

Storage Range

−65°C to +125°C

Lead Soldering (60 sec)

300°C

ESD Rating

2 kV

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 3. Thermal Resistance

Package Type

θJA

Unit

CP-20-10 LFCSP Without Thermal Pad

°C/W

CP-20-10 LFCSP With Thermal Pad

°C/W
