UNISONIC TECHNOLOGIES CO., LTD

UT2302

Power MOSFET

www.unisonic.com.tw

1 of 5

Copyright © 2010 Unisonic Technologies Co., Ltd

QW-R502-114.G

N-CHANNEL

ENHANCEMENT MODE

DESCRIPTION

The UTC UT2302 is N-channel Power MOSFET, designed with

high density cell, with fast switching speed, ultra low on-resistance,

and excellent thermal and electrical capabilities.

Used in commercial and industrial surface mount applications and

suited for low voltage applications such as DC/DC converters.

SYMBOL

2.Gate

1.Source

3.Drain

ORDERING INFORMATION

Ordering Number

Pin Assignment

Lead Free

Halogen Free

Package

1

2

3

Packing

UT2302L-AE2-R

UT2302G-AE2-R

SOT-23-3

S

G

D

Tape Reel

UT2302L-AE3-R

UT2302G-AE3-R

SOT-23

S

G

D

Tape Reel

MARKING

23B

L: Lead Free

G: Halogen Free
