U74LVC1G00
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
2 of 6
www.unisonic.com.tw
QW-R502-401.B
PIN CONFIGURATION
FUNCTION TABLE
INPUT(A)
INPUT(B)
OUTPUT(Y)
H
H
L
H
L
H
L
H
H
L
L
H
Note: H: HIGH voltage level; L: LOW voltage level.
LOGIC DIAGRAM (positive logic)
Logic symbol
IEC logic symbol
