5 / 12 page

DIMENSIONAL

SPECIFICATIONS

INCHES

(MM)

2" NPT

Process Connection

3.00" (76)

Insertion Length

4.63 (118)

Dia.

3.00 (76)

2.75

(70)

4.50

(114)

2.12 (54)

Insertion Dia.

2" NPT

Process

Connection

3/4" NPT

10.00" (254)

Insertion Length

2.12 (54)

Insertion Dia.

3.00

(76)

29.00

(736)

1.50

(38)

3.12

(79)

6.12

(155)

20.50 (520)

22.50 (571)

2.00

(50)

2" Female NPT

(P/N 36-3813-001)

20.50

(520)

22.50

(571)

3.00

(76)

1.50

(38)

2.00

(50)

3.12

(79)

2" Female NPT

(P/N 36-3812-001)

Floor Mount Bracket

Wall Mount Bracket

OPTIONAL

MOUNTING

BRACKETS

MODEL

384

TRANSDUCERS

2" NPT

Process

Connection

3.00" (76)

Insertion Length

2" NPT

Process

Connection

10.00" (254)

Insertion Length

1" NPT

Process

Connection

3.00" (76)

Insertion Length

1" NPT

Process

Connection

10.00" (254)

Insertion Length

2.12 (54)

Insertion Dia.

2.12 (54)

Insertion Dia.

2.12 (54)

Insertion Dia.

2.12 (54)

Insertion Dia.

2" NPT Transducer with Housing

1" NPT Transducer without Housing

2" NPT Transducer without Housing
