PRELIMINARY

TECHNICAL DATA SHEET

6 Lake Street, Lawrence, MA 01841

Gort Road Business Park, Ennis, Co. Clare, Ireland

1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803

Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298

Website: http://www.microsemi.com

T4-LDS-0107 Rev. 1 (091991)

Page 3 of 3

SCHEMATIC

FIGURE 2 – Physical dimensions, surface mount U3 (SMD.5)

NOTE:

Dimensions

1. Dimensions are in inches.

Symbol

Inches

Millimeters

2. Millimeters are given for general information only.

Min

Max

Min

Max

3. In accordance with ASME Y14.5M, diameters are

.395

.405

10.04

10.28

equivalent to

φx symbology.

.291

.301

7.40

7.64

.1085

.1205

2.76

3.06

.010

.020

0.25

0.51

LW1

.281

.291

7.14

7.41

LW2

.090

.100

2.29

2.54

LL1

.220

.230

5.59

5.84

LL2

.115

.125

2.93

3.17

LS1

.150 BSC

3.81 BSC

LS2

.075 BSC

1.91 BSC

.030

0.762

.030

0.762
