UNISONIC TECHNOLOGIES CO., LTD

4052

CMOS IC

www.unisonic.com.tw

1 of 6

Copyright © 2010 Unisonic Technologies Co., LTD

QW-R502-013.D

DIFFERENTIAL 4-CHANNEL

ANALOG MULTIPLEXERS/

DEMULTIPLEXERS

DESCRIPTION

The UTC 4052 is differential 4-channel analog multiplexers/

demultiplexers for application as digitally–controlled analog switches.

The device has two binary control inputs and an inhibit input. It

feature low ON impedance and very low OFF leakage current.

Control of analog signals up to the complete supply voltage range

can be achieved.

FEATURES

* Break-Before-Make Switching Eliminates Channel Overlap.

* Linearized Transfer Characteristics

* Implement an DP4T Switch Effectively.

* Pin to Pin Replacement for CD4052

ORDERING INFORMATION

Ordering Number

Normal

Lead Free Plating

Halogen Free

Package

Packing

4052-D16-T

4052L-D16-T

4052G-D16-T

DIP-16

Tube

4052-P16-R

4052L-P16-R

4052G-P16-R

TSSOP-16

Tape Reel

4052-S16-T

4052L-S16-T

4052G-S16-T

SOP-16

Tube

4052-S16-R

4052L-S16-R

4052G-S16-R

SOP-16

Tape Reel
