2 / 9 page

BSS131

Parameter

Symbol Conditions

Unit

min.

typ.

max.

Thermal characteristics

Thermal resistance,

junction - minimal footprint

R thJA

350

K/W

Electrical characteristics, at T j=25 °C, unless otherwise specified

Static characteristics

Drain-source breakdown voltage

V (BR)DSS V GS=0 V, I D=250 µA

240

Gate threshold voltage

V GS(th)

V DS=0 V, I D=56 µA

0.8

1.4

1.8

Drain-source leakage current

I D (off)

V DS=240 V, V GS=0 V,

T j=25 °C

0.01

µA

V DS=240 V, V GS=0 V,

T j=150 °C

Gate-source leakage current

I GSS

V GS=20 V, V DS=0 V

Drain-source on-state resistance

R DS(on)

V GS=4.5 V, I D=0.09 A

9.07

Ω

V GS=10 V, I D=0.1 A

7.7

Transconductance

g fs

|V DS|>2|I D|R DS(on)max,

I D=0.08 A

0.06

0.13

Values

Rev. 2.

page 2

200

9-08-18
