AD8494/AD8495/AD8496/AD8497

Rev. 0 | Page 5 of

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

±18 V

Maximum Voltage at −IN or +IN

+VS – 25 V

Minimum Voltage at −IN or +IN

–VS + 25 V

REF Voltage

±VS

Output Short-Circuit Current Duration

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Maximum IC Junction Temperature

140°C

ESD

Human Body Model

4.5 kV

Field-Induced Charged Device Model

1.5 kV

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θJA is specified for a device on a 4-layer JEDEC PCB in free air.

Table 4.

Package

θJA

Unit

8-Lead MSOP (RM-8)

135

°C/W

ESD CAUTION
