RF2128P
Rev A4 990216
2
Absolute Maximum Ratings
Parameter
Rating
Unit
Supply Voltage (VCC)
-0.5 to +7.5
VDC
Power Down Voltage (VPD)
-0.5 to +5.5
V
DC Supply Current
125
mA
Input RF Power
+12
dBm
Output Load
20:1
Operating Ambient Temperature
-40 to +85
°C
Storage Temperature
-40 to +150
°C
Parameter
Specification
Unit
Condition
Min.
Typ.
Max.
Overall
T=25 °C, VCC=5V, VPD=5.0V,
Freq=2400MHz
Frequency Range
1900 to 2500
MHz
Maximum Output Power
+22
dBm
VCC=5.0V, VPD=5.0V, PIN=-3.0dBm
>+24
dBm
VCC=6.0V, VPD=5.5V, PIN=0dBm
1dB Compression Output Power
+21
dBm
Total CW Efficiency
33
%
Maximum output
Small-signal Gain
28
dB
Second Harmonic
-23
dBc
Third Harmonic
-19
dBc
Isolation
15
dB
VPC=0.2V
Input VSWR
2:1
Input Impedance
50
Ω
Noise Figure
7
dB
Two-tone Specification
Average Two-Tone Power
+17
dBm
PEP- 3dB
IM3
-27
dBc
POUT=+14dBm for each tone
IM5
-40
dBc
POUT=+14dBm for each tone
IM7
-44
dBc
POUT=+14dBm for each tone
Two-Tone Power-Added
Efficiency
30
%
Power Down Control
Power Down “ON”
VCC
V
Voltage supplied to the input; device is “on”
Power Down “OFF”
01.2
V
Voltage supplied to the input; device is “off”
Power Supply
Voltage
5
V
Specifications
3.0 to 6.5
V
Operating
Current
50
65
mA
Operating Idle
85
mA
At maximum output power
Current
10
µAPower Down
Caution! ESD sensitive device.
