5 / 22 page

MB-0054-8

5/22

[JN2]

Component

Material / Finish

Receptacle Pin insulator

Synthetic resin

Shell

Zinc die-cast / Zinc plating

Pin contact

Copper alloy / Au plating (10 pin),

Silver plating (4 pin.)

Plug

Front insulator

Synthetic resin

Rear insulator

Synthetic resin

Coupling nut

Zinc die-cast / Zinc plating (Black)

Assembly nut

Zinc die-cast / Zinc plating (Black)

Angle endbell

Synthetic resin

Straight endbell

Synthetic resin

O Ring

Synthetic rubber

Bushing*

Synthetic rubber

(Color: black/gray/brick red/dark green)

Grand nut

Synthetic resin

Spring

Stainless steel

Spring pin

Stainless steel

Socket contact

Copper alloy / Au plating (10 pin),

Silver plating (4 pin)

*Color of bushing is determined by applicable wire size. (Same for JN1, JN2)

6.5 to 8.0 Dia.

Gray

5.7 to 7.3 Dia.

Black

3.5 to 5.0 Dia.

Brick Red

Applicable Cable

4.7 to 5.7 Dia.

Dark Green

4, 10 pos.

Color of Bushing
