4 / 12 page ![]() ADP195 Rev. 0 | Page 4 of 12 ABSOLUTE MAXIMUM RATINGS Table 2. Parameter Rating VIN to GND −0.3 V to +4.0 V VOUT to GND −0.3 V to VIN EN to GND −0.3 V to +4.0 V Continuous Drain Current TA = 25°C ±2 A TA = 85°C ±1.1 A Continuous Diode Current −50 mA Storage Temperature Range −65°C to +150°C Operating Junction Temperature Range −40°C to +125°C Soldering Conditions JEDEC J-STD-020 Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. This is a stress rating only; functional operation of the device at these or any other conditions above those indicated in the operational section of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability. Table 3. Typical ΨJB Values Package ΨJB Unit 4-Ball WLCSP 58.4 °C/W ESD CAUTION |
|
|
