MIM-R1AA38

Absolute Maximum Ratings

Item

Symbol

Ratings

Unit

Remark

Supply voltage

VCC

5.8

Operating temperature

Topr

-10 ~ + 60

°C

Storage temperature

Tstg

-20 ~ + 75

°C

Soldering temperature

Tsd

260

°C

Maximum 5 seconds

Electro-optical characteristics (VCC=5V)

Parameter

Symbol

Min.

Typ.

Max.

Unit

Remarks

Current consumption

Icc

5.0

Under no signal

Response wavelength

940

Tuning frequency

37.9

KHZ

Output form

- - - - - active low output - - - - -

H level output voltage

V0h

4.2

L level output voltage

V0l

0.5

H level output pulse width

Twh

400

800

L level output pulse width

Twl

400

800

10.0

Note 1

Half angle

±16

±55

deg

Horizonal direction

Test Method

A. Standard Transmitter

Distance between emitter &detector

Unity Opto Technology Co., Ltd.

@ T

A=25°C

@ T

A=25°C

carrier frequency f0

duty 50%

ON/OFF pulse width satisfied from 20 cm to detection limit

600

µs

600

µs

600

µs

Fig 1.Burst Wave

+5v

Vout

20cm

Transmitter

Duty 50%

Oscilloscope

Fig 2.Standard Transmitter Measurement circuit

10k

Ω
