ADA4004-1/ADA4004-2/ADA4004-4

Rev. E | Page 5 of 16

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage

±18 V or +36 V

Input Voltage

V− < VIN < V+

Differential Input Voltage

±V supply

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θJA is specified with the device soldered on a circuit board with

its exposed paddle soldered to a pad (if applicable) on a 4-layer

JEDEC standard printed circuit board with zero airflow.

Table 5.

Package Type

θJA

θJC

Unit

5-Lead SOT (RJ-5)

230

°C/W

8-Lead SOIC (R-8), ADA4004-1

177

°C/W

8-Lead SOIC (R-8), ADA4004-2

155

°C/W

8-Lead MSOP (RM-8)

186

°C/W

14-Lead SOIC_N (R-14)

115

°C/W

16-Lead LFCSP_VQ (CP-16-4)

31.5

°C/W
