background image
Power Chip Shielded Inductors
PCSDR73
15
DCR
(Ω)
I sat
Allied
Part
Number
Inductance
(
µh)
Tolerance
(%)
Test
Freq.
PCSDR73-R56M-RC
PCSDR73-1R5M-RC
PCSDR73-2R2M-RC
PCSDR73-2R7M-RC
PCSDR73-3R3M-RC
PCSDR73-5R6M-RC
PCSDR73-8R2M-RC
PCSDR73-100M-RC
PCSDR73-120M-RC
PCSDR73-150M-RC
PCSDR73-180M-RC
PCSDR73-220M-RC
PCSDR73-270M-RC
PCSDR73-330M-RC
0.56
1.5
2.2
2.7
3.3
5.6
8.2
10
12
15
18
22
27
33
20
20
20
20
20
20
20
20
20
20
20
20
20
20
100
100
100
100
100
100
100
100
100
100
100
100
100
100
0.0106
0.0156
0.0198
0.0254
0.0311
0.0439
0.0710
0.0787
0.0900
0.1013
0.1148
0.1284
0.1638
0.1992
10.286
6.545
5.538
4.800
4.235
3.429
2.667
2.483
2.323
2.057
1.846
1.674
1.532
1.358
ALLIED COMPONENTS INTERNATIONAL
714-665-1140
www.alliedcomponents.com
RoHS
PCSDR73-4R7M-RC
4.7
20
100
0.0356
3.789
PCSDR73-6R8M-RC
6.8
20
100
0.0522
3.130
(A)
PCSDR73-470M-RC
PCSDR73-560M-RC
PCSDR73-680M-RC
PCSDR73-820M-RC
47
56
68
82
20
20
20
20
100
100
100
100
0.2892
0.3594
0.4296
0.4608
1.143
1.075
0.960
0.889
PCSDR73-390M-RC
39
20
100
0.2442
1.263
PCSDR73-101M-RC
PCSDR73-121M-RC
100
120
20
20
100
100
0.6324
0.8268
0.791
0.727
PCSDR73-181M-RC
PCSDR73-221M-RC
180
220
20
20
100
100
1.1406
1.2600
0.595
0.533
PCSDR73-151M-RC
150
20
100
1.0212
0.649
PCSDR73-271M-RC
270
20
100
1.5840
0.483
REVISED 6/9/09
KHz, 0.1V
All specifications subject to change without notice.
I rms
(A)
PCSDR73-331M-RC
330
20
100
1.9080
0.442
PCSDR73-391M-RC
390
20
100
2.3700
0.402
PCSDR73-471M-RC
470
20
100
2.8320
0.369
PCSDR73-561M-RC
560
20
100
3.4980
0.338
PCSDR73-681M-RC
680
20
100
4.1640
0.306
PCSDR73-821M-RC
820
20
100
4.7160
0.278
PCSDR73-102M-RC
1000
20
100
5.2080
0.253
PCSDR73-1R0M-RC
1.0
20
100
0.0122
8.000
5.686
5.281
4.678
4.152
3.663
3.314
3.095
2.788
2.557
2.192
2.083
1.948
1.836
1.724
1.631
1.444
1.309
1.182
1.087
0.975
0.891
0.861
0.735
0.643
0.578
0.547
0.521
0.464
0.423
0.380
0.347
0.312
0.286
0.269
0.256
PCSDR73-R33M-RC
0.33
20
100
0.0088
14.400
6.243
Features
• Magnetically Shielded
• Expanded operating temp range
• Low DC Resistance
• High Energy Storage
Electrical
Test Equipment
Physical
Packaging: 1000 pieces per 13 inch reel.
• High saturation current as high as 14A
Inductance Range: .33µh to 1200µh
Tolerance: 20% entire inductance range
Test Frequency: 1KHz, 0.1V
Operating Temp: -55ºC ~ +125ºC
Irms: Current at which the
Resistance to Soldering Heat
Pre-Heat 150ºC, 1 Min.
Solder Composition: Sn/Ag3.0/Cu0.5
Solder Temp: 260ºC +/- 5ºC
Immersion time: 10 sec. +/- 1 sec.
(L):
HP 4284A LCR meter or equivalent
(RDC):
HP 4338B Millohm meter or equivalent
(IDC): 3260B WK & DC Bias 3265B WK
Marking:
EIA Inductance Code.
Available in tighter tolerances
• Low Energy Loss
• Suitable for pick and place
∆ T=40ºC
Isat: Current at which the inductance
drops 35% from initial value
Storage Temp: -40ºC ~ +85ºC
PCSDR73-122M-RC
1200
20
100
7.8916
0.230
0.208
Dimensions:
Inches
(mm)
Schematic
