S S L 0 6 0 5 - R 1 0 Y F

(a)

(c)

(b)

(e)

(d)

1. PART NO. EXPRESSION :

(b) Dimension code

(c) Inductance code : R10 = 0.10uH

(a) Series code

2. CONFIGURATION & DIMENSIONS :

A

SUPERWORLD ELECTRONICS (S) PTE LTD

3. SCHEMATIC :

(d) Tolerance code : Y = ±30%

(e) F : Lead Free

SSL0605 SERIES

HIGH CURRENT POWER INDUCTORS

PG. 1

NOTE : Specifications subject to change without notice. Please check our website for latest information.

05.05.2008

PCB Pattern

7.2 Max.

5.0 Max.

1.5±0.5

BC

D

6.8 Max.

Unit:m/m

2.5 Max.

G

E

2.5±0.5

Inductance L ( uH )

0.10 ±30%

5. ELECTRICAL CHARACTERISTICS :

SSL0605-R10YF

SSL0605-R20YF

SSL0605-R15YF

Part No.

30

0.25V/1M

19

24

Freq.

Test

0

Irms

Max.

( A )

0.50

37

24

0.50

30

0.50

DCR

Isat

Max.

( A )

( m

)

Max.

R10

A

D

L

G

4.5 Max.

7.5 Max.

HL

e) Part temperature (ambient + temp. rise) : Should not exceed 125°C under worst case operating conditions.

d) Isat (A) : Will cause L to drop approximately 20%

a) Operating temp. : -55°C to +125°C

b) Storage temp. : -55°C to +125°C

c) Irms (A) : Will cause coil temp. to rise approximately

T=40°C without core loss.

4. GENERAL SPECIFICATION :

0

0.15 ±30%

0.20 ±30%

( Hz )

0.25V/1M

0.25V/1M
