OC-48 LR-1/STM16 L-16.1 SFP Transceiver

SP-48-LR1

20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486

9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213

LUMINENTOIC.COM

LUMNDS1524-Jul0507

Rev A.1

Parameter

Range

Accuracy

Unit

Calibration

Formula

Temperature (-CDA)

-5 to 70

±3

ºC

External

Tc(C) = Tslope*Tad(16 bit signed twos complement value) + Toffset

Temperature (-RDA)

-20 to 85

±3

ºC

External

Tc(C) = Tslope*Tad(16 bit signed twos complement value) + Toffset

Temperature (-TDA)

-40 to 85

±3

ºC

External

Tc(C) = Tslope*Tad(16 bit signed twos complement value) + Toffset

Voltage

0 to Vcc

0.1

V

External

V(Volts) = Vslope*Vad (16 bit unsigned integer) + Voffset

Bias Current

0 to 120

5

mA

External

I(mA) = Islope * Iad(16 bit unsigned integer)+Ioffset

Tx Power

-2 to 3

±3dB

dBm

External

Tx_PWR(µW) = Tx_PWRslope*Tx_PWRad(16 bit unsigned integer)+Tx_

PWRoffset

Rx Power

-31 to -6

±3dB

dBm

External

Rx_PWR(µW) = A0+A1*x+A2*x^2+A3*x^3+A4*x^4

Diagnostics

Name of Field

Discription of Field

Address

Hex

ASCII

Vendor Name

SFPVendor name (ASCII)

20

4C

L

21

55

U

22

4D

M

23

49

I

24

4E

N

25

45

E

26

4E

N

27

54

T

28

4F

O

29

49

I

30

43

C

Vendor OUI

IEEE vendor OUI code for LuminentOIC Inc.

37

00

38

06

39

B5

Vendor PN

Part number in ASCII, e.g.

SP-48-LR1-CDA

40

53

S

41

50

P

42

34

4

43

38

8

44

4C

L

45

52

R

46

31

1

47

43

C

48

44

D

49

41

A

EEPROM Serial ID
