Pluggables

Physical Specifications

Operating Temperature Range

0

Storage Temperature

-40

Relative Humidity

85% maximum, non-condensing

Power

1.5 W

Regulatory Compliance

FCC Part 15 (Class A); IC (Class A); EMC Directive: Emission (Class A) and Immunity; RoHS Directive;

China RoHS; WEEE Directive: Wheelie Bin Mark

Comparison Table

SFP-GC-R

SFP-GA-R

SFP-SW10/100-R

RJ-45 connector

Yes

Yes

Yes

Cable type

CAT-5

CAT-5

CAT-5

Maximum cable length (m)

100

100

100

Ethernet Standard

1000 Base-T

1000 Base-T

10/100 Base-TX

Supports speed auto-negotiation

N/A

Yes

Yes

Supports duplex auto-negotiation

N/A

Yes

Yes

Supports auto MDI/MDI-X detect

Yes

Yes

Yes

Match translates between edge devices

No. Both edge devices must operate

in the same duplex mode.

No. Both edge devices must operate

in the same duplex mode.

Yes

Used with Layer 0/1 devices (e.g. repeaters

converters and WDM transponders)

Yes

No

Yes

Used with Layer 2 devices, e.g. switches

and routers

No

Yes

Yes

Packet Size (bytes)

9600 +

9600 +

1600

Outline Drawing for SFP-GC-R and SFP-GA-R
